2012 09 "PHC" Explorations

Espiegel123 September 15, 2012 User blog:Espiegel123
2618 phc slightly slightly diluted 06 cropped
For some time, I have wanted to see if I could make use of CMC (Sodium CarboxyMethylCellulose) which was reported to me by a chemist to be the most beneficial polymer for bubble juice other than PEO. I had some disappointing attempts a year or two ago to make a juice that was CMC-based. This was around the time that I was having a lot of success with PEO-only and HEC-only mixes.

I had some nice sessions at the time with CMC-based mixes, but I didn't come up with any juice that was as good as my best PEO or HEC mixes. The CMC mixes seemed "tighter" than HEC or PEO mixes. When there was enough CMC to make water/detergent bubble-friendly, the solution also resulted in a "tight" skin. The bubbles were less self-healing than PEO or HEC bubbles and, with large loops, the size potential was less. I put my exploration of CMC on hold as there seemed like other more pressing/fruitful lines of inquiry to pursue.

Some months later, there was a discussion on SBF, the Soap Bubble Fanciers Yahoo Group, of CMC. A couple of people mentioned that they were finding HPMC+CMC to be beneficial to PEO-based mixes in a way that neither HPMC or CMC were. One of these people mentioned that they found no (or little) benefit to HPMC as a secondary polymer (with PEO as the primary) but great benefit to the HPMC plus CMC combination.

I have also been curious about exploring more viscous mixes since one of my good bubble friends likes PEO-based mixes that have more viscosity than what one can get with PEO-alone (without oeverdosing). With PEO, it isn't possible to get the mix to be very viscous without overdosing with PEO. The high molecular weight PEO that we use (J-Lube or WSR301) overdoses a mix long before it makes a big dent on viscosity. By contrast, HEC mixes will become too thick for use before the HEC makes the mix un-bubbleable.

My first experiment involved the addition of the suggested amounts of HPMC and CMC. The suggestion was basically to use Jumbo Juice like concentrations plus the addition of twice as much high viscosity CMC as HPMC (K15M). I mixed up three mixes, eGoo, PEO plus HPMC, and PEO plus HPMC and CMC. The HPMC + CMC mix was noticeably better than the HPMC-only mix but no better than the eGoo I had on-hand.

Granted, that was just one test and multiple sessions are really necessary to get conclusive results, but time is fleeting. Perhaps, someone might have liked the slightly different flow, but the bubbles themselves didn't seem to be improved (nor hurt).

I decided that for the next trials, I should go more extreme -- push the PEO limits a bit and increase the amount of HPMC and CMC quite a bit to achieve a mix that is noticeably more viscous. Co-incidentally, this was about a week before I had my first (and, so far, only) experience with the Bangwool bubble juice (with which I had some great success -- see the video ).

Version 1.0: I decided to try somewhat ridiculous amounts figuring that I could always dilute (with water and detergent) as necessary. I somewhat arbitrarily decided on these amounts:

  • 1.5 gr hpmc powder (Methocel K15M)
  • 3.0 gr cmc (Aqualon 7h4f)
  • 1.0 gram degraded wsr301 (in freezer) [I guess this is about 1/3 to 1/4 the potency of 'fresh PEO from hell']
  • 146 grams Dawn Pro
  • 7 grams baking soda
  • 3644 grams water
  • 3.5 grams citric acid

The result is a very thick mix that is a bit stringy. With small loops, the size potential seems less than my standard PEO or guar-based mixes. However, when I tried it with very large loops (well, very large for me) on the order of a 100" top-string, I found it to work at least as well if not better than my standard mix. With such large loops, the issues that influence maximum size are different than with smaller loops.

Ihave not yet done enough head-to-head trials to know if this mix is actually working better than the PEO-only juice, but it worked well enough that I want to explore it some more.

Here are a few pictures from the Sept. 14, 2012 test session. The humidity was good (it started at 80% and was down to 70% 1/2 hour later when I finished up) and the temp about 65F. I did not close as many monsters as I did the other day when testing the Bangwool solution nor were the biggest bubbles as big as in the Bangwool session. However, during the Bangwool session the humidity was higher and the slight wind had an updraft that was helpful.

I notice in reviewing the video that almost all the bubbles broke on the top far from the attachment points. So, the problem closing the bubbles had more to do with the life-expectancy of the film rather than bubble-ability.

Besides comparing to PEO-only mixes, I also want to try a mix that has uses less PEO but holds the other ingredients steady.

VERSION 1.1:

20120918 phc11 5
PHC 1.1. Humidity 70%. Temp: 60F.
Espiegel123Added by Espiegel123
On Sept. 17, I mixed up a version with less PEO and a slightly different mixing protocol which I am calling version 1.1. It worked quite well in a Sept. 18, 2012 test session. You can watch video of the session here .

Slurry the polymer mix with 20 grams glycerine:

  • 0.5 grams (quarter-potency) wsr301
  • 1.5 grams HPMC (K15M)
  • 3.0 grams CMC (7H4F)

Add 146 grams dawn pro [this is to be mixed with 3644 total grams water for 25:1 water:detergent ratio]

Add 7 grams baking soda

Add 200 grams hot water and stir

Add 300 grams hot water and stir

Measure 3144 grams water into a gallon jug

Put citric acid in a glass and pour in enough water from the jug to easily dissolve the citric acid (maybe 50 ml water)

Add polymer goo to the jug and turn over a few times to mix

Add citric acid water

One hour after mixing it gets 5 to 8 colorful bubbles when using a small plastic wand. The mix is a bit stringy and thick.

Version 1.2

2702 100inch phc12 5 CROP
100-inch top string (full-ply mop yarn) with single-ply rayon mop strand
Espiegel123Added by Espiegel123
Since part of my reason for exploring this mix was to see if there is anything to the conjecture offerred by a chemist on SBF that multi-polymer mixes are inherently worse than well-tuned single-polymer mixes, I decided that I need to see how crazy thick one can go with this. I am also curious to see in what ways the performance changes with viscosity. Version 1 turns out to seem thick compared to a straight PEO juice, but it isn't really all that viscous in absolute terms.

So, I decided to really up the amount of HPMC and CMC. 1.2 users these amounts of polymer:


  • 2.5 gr hpmc powder (Methocel K15M) [5 heaping 1/4 tsp]
  • 5 gr cmc (Aqualon 7h4f) [5+ heaping 1/4 tsp]
  • 1.0 gram degraded wsr301 (in freezer) [I guess this is about 1/3 to 1/4 the potency of 'fresh PEO from hell'] [2+ level 1/4 tsp]

2703 100inch phc12 1 CROP
PHC12. 100-inch top-string loop. (Full-ply top; single strand bottom)
Espiegel123Added by Espiegel123
I haven't yet measured the viscosity of this solution. I had a nice test session with it on 2012/09/26, but I can't drawn any conclusions yet about its performance relative to the other two versions or a straight PEO mix. Analyzing the one test session is a bit tough because conditions were changeable AND there is roadwork being done in the neighborhood with occasional gusts of diesel wafting our way.



The next step is to go even more viscous. I had expected this version to be viscous to the point of unusability but it wasn't outrageously thick.

Version 1.3

A libman phc13 3a 20121010
PHC 1.3 with 1/8 part Mr. Bubbles to reduce ghosts
Espiegel123Added by Espiegel123
This version is intended to be ridiculously thick to see if the extra viscosity is beneficial for making giant tubes and bubbles with the 100" top string. The exploration of slow flowing solutions is to see if this quality of the Bangwool solution that created such large bubbles is generally useful. It is quite possible that the high viscosity of the Bangwool solution is a side-effect of the chemistry that creates such a nice mix and not the cause. This solution -- given the ridiculously large amounts of polymers -- should also give some insight into the validity of John P's claim on SBF that using HPMC and CMC along with PEO will result in a solution inferior to one that is PEO only.

For the base recipe, see above but substitute this amount of polymer powders.

  • 4 grams HPMC (K15M)
  • 8 grams CMC (Aqualon 7H4F)
  • 1 gram WSR301 (of degraded PEO that is approximately 1/4 strength)
A libman bottom phc13 CROP 20121010
Another picture form the 2012 10 10 session.
Espiegel123Added by Espiegel123
This recipe creates some pretty magnificent "ghosts". To test Louis Pearl's claim that Mr. Bubbles can reduce or eliminate ghosting, I did some tests and found that 1-1/2 cups of Mr. Bubbles added to one quart of PHC.13 eliminated the ghosts. I didn't notice any other dramatic changes to the solution's behavior when the Mr. B was added. The pictures in this section had maybe 1/2 cup Mr. B in about 6-8 cups PHC1.3
A libman phc13 2 20121010
PHC1.3 (plus some Mr. Bubbles). 2012 10 10 session.
Espiegel123Added by Espiegel123
